Micro Fog
SKU: 629XMF / 627XMF
View Product on Marketing Website
Eastman’s exclusive Micro Fog machine ensures maximum heat reduction for cutting highly fusible materials and plastics. The Micro Fog device sends a mist of coolant / lubricant, assisted by 90-120 psi compressed air, behind the knife and out through a specially slotted wave-edged blade. This allows coolant to penetrate every layer, eliminating the conditions that cause fusing. The Micro Fog is ideal for cutting Cordura® , PVC plastic or polyester, and vinyl.
The Micro Fog™ is available in a standard version, 629XMF, and a heavy-duty version, 627XMF.
All Eastman machines are built with the highest grade materials available.
Categories
Manual Cutting, Straight Knives
Product Attributes
| Motors |
110V, 1ph, 50/60Hz 220V, 1ph or 3ph, 50/60Hz 380V, 3ph, 50Hz Standard: Single Speed Optional: Dual Speed |
|---|---|
| Horsepower |
.65hp, 1ph .93hp, 3ph |
| Weight |
34 lbs. (15.4kg) |
| Pneumatic |
90-120 psi (6.2-8.3 bars) |
| Blades |
Wave Groove |
| Belts |
Standard: Medium Grit Optional: Fine, Coarse, Rough |
| Options |
Micro Fog only available for 6 in. and 8 in. |
| Stroke Sizes |
1.125 in. (2.86cm) 1.25 in. (3.18cm) 1.5 in. (3.81cm) 1.75 in. (4.45cm) |
| Blade Sizes |
6 in (15.2 cm) 8 in. (20.3 cm) |
| Cutting Capacity |
4.5 in. (11.4cm) 6.5 in (16.5cm) |
